E4990/E5690 Brushless Motor For RC Cars
Name
  • E4990/E5690 Brushless Motor For RC Cars
Type
  • BLDC
Parameters
  • Model

    E4990

  • E4990-KV

    1650KV

  • E4990 Cells

    3-8S

  • E4990 No-load Current

    ≤7.0A

  • E4990 Outer Diameter/Length

    Ø56mm(2.205in)/L90mm(3.543in)

  • E4990 Shaft Diameter/End Length of

    Ø8mm(0.315in)/L30mm(1.181in)

  • E4990 Bearing Specification

    D22*d8*T7 Front end (Driving end)

  • E4990 Bearing Specification

    D19*d8*T6 Rear end (Terminal)

  • E4990 Pairs of poles

    2 Pairs of poles

  • E4990 Application

    1/7 On-road, Short Course, Truck,1/8 Monster(Heavy-duty)

  • Model

    E5690

  • E5690-KV

    1250KV

  • E5690 Cells

    3-8S

  • E5690 No-load Current

    ≤5.8A

  • E5690 Outer Diameter/Length

    Ø49mm(1.929in)/L90mm(3.543in)

  • E5690 Shaft Diameter/End Length of

    Ø5mm(0.197in)/L21.5mm(0.846in)

  • E5690 Bearing Specification

    D19*d8*T6 Front end (Driving end)

  • E5690 Bearing Specification

    D19*d8*T6 Rear end (Terminal)

  • E5690 Pairs of poles

    2 Pairs of poles

  • E5690 Application

    1/6 Short Course, Monster, 1/5 Light-duty Truck

Functions and features
